Technical Specifications

• Frequency response (-3 dB) (Hz): 67 Hz – 20,000 Hz
• Frequency range (-10 dB) (Hz): 55 Hz – 20,000 Hz
• Axial sensitivity (dB SPL 1W/1m): 90 dB SPL 1W/1m
• Maximum sound pressure level at a distance of 1 m (dB): 124 dB
• High pass frequency (Hz): 60 Hz
• Crossover frequency (kHz): 2 kHz
• Coverage angle HxV (°): 90° x 60°
• Power handling (continuous) (W): 250 W
• Power handling (peak) (W): 1,000 W
• Nominal impedance (Ω): 8Ω
• LF transducer: WECA2088
• LF transducer size (in): 8 in
• LF transducer magnet material: Ferrite
• HF transducer: DH-1K
• HF transducer type: Compression driver
• HF transducer size (in): 1.4 in
• HF transducer diaphragm material: Titanium
• Dimensions (H x W x D) (mm): 459.6 mm x 289.9 mm x 280.5 mm
• Dimensions (H x W x D) (in): 18.09 in x 11.41 in x 11.04 in
• Shipping dimensions (H x W x D) (mm): 500 mm x 390 mm x 350 mm
• Shipping dimensions (H x W x D) (in): 19.69 in x 15.35 in x 13.78 in
• Weight (kg): 10.15 kg
