Omnitronic CM-5300 Club-Mixer Professional 5-channel club mixer


    High-grade stereo mixer for clubs and numerous mobile PA applications
    5 stereo input channels with gain control, 3-band kill EQ (+12/ -26dB) and 10-digit LED level meter
    Front panel aux input
    Rear stereo input FOH for stage mixers
    Smooth dual-rail channel input faders (60 mm/100 mm)
    3 microphone input channels with front combo connector
    Gain control, peak LED, 3-band EQ and on air switch per microphone channel
    One-knob compressor per microphone channel
    2-parameter adjustable auto talkover for automatic music level reduction when microphone is used
    Fully assignable smooth dual-rail crossfader (45 mm)
    Master section with two separately controllable stereo outputs, output 2 switchable to mono
    10-digit stereo LED level meter, switchable between both master outputs
    Balanced XLR and unbalanced main outputs
    Additional mono zone output (with switchable 80Hz HPF) which can be routed to the master bus or channel 5
    10-digit LED level meter for the zone output
    Mono subwoofer output with integrated active crossover (frequency/level adjustable)
    All outputs with rear-side maximum level setting controls
    Adjustable effects send/return path, assignable to mic or master bus
    PFL section with PFL/master mix control and cue mix/split option
    Record output, independent of the master
    Rack installation, 7 U

Power supply:    115/230 V AC, 50/60 Hz
Power consumption:    25 W
Inputs:
MIC 1-3:    combination XLR/6.3 mm jack bal.
LINE 1-5:    RCA L/R
PHONO 1,2:    RCA L/R
AUX:    3.5 mm stereo jack
FOH:    6.3 mm jack bal.
FX RETURN:    6.3 mm jack unbal.
Outputs:
MASTER 1,2:    XLR L/R bal., RCA L/R
ZONE:    XLR bal.
SUB:    XLR bal.
REC:    RCA L/R
FX SEND:    6.3 mm jack unbal.
PHONES:    6.3 mm jack unbal.
Frequency range:    20-20 000 kHz
Distortion:    0.05 % (line)
S/N ratio:    >82 dB (line)
Dimensions (LxWxH):    383 x 483 x 106 mm (19", 7 U)
Weight:    6 kg
Shipping weight:    8.00 kg
